All our residential single and double door locks are designed using Multipoint ‘Hook’ locks as standard adding to the overall performance and durability of the entrance to your home.
24mm Throw Tensile Steel Security Hooks
Opposing High Security steel hooks ‘barb’ behind keeps by 8mm to help prevent the forcing apart of sash and frame.
Unique Compression Cam
Spring loaded cam can be lifted and turned by hand to ‘fine tune’ operating forces and weather seal compression. These roller cams act in conjunction with the hook locks to give added strength and security.
Cylinders and handles
Our Multi-Point Lock has been designed to harmonise with range of security profile cylinders and is compatible with industry standard handles. Our specially designed door handle adds a touch of sophistication for homes of distinction
Steel Keep Rail
Massive 35mm or 38mm wide keeps are available as either full length or single pocket options and fitted with metal dust pockets for security and stability.
Inline screw fixing holes help ensure that the keeps are securely fastened through the PVCu profile into the reinforcement.
Manufactured using high grade steel to comply with highest Grade 4 corrosion resistance requirement.
High Grade Centre Keep
8mm diameter clearance holes designed to allow frame fixing bolts to be inserted through the keep rail for increased strength against intruder attack.
Heavy Duty steel faceplate
Special ‘silver’ finish 3mm thick faceplate for improved security and providing rigid fixing and support to the PVC Euro groove.
Latch and Centre Hook
Nickel plated spring latch with 6mm thick tri-laminate steel ‘anti-lift’ centre hook with 20mm throw.
High Performance gearbox
Designed to comply with the latest requirements of PAS23/PAS24 standard for enhanced Security Doorsets. The gearbox offers the lowest possible operating force performance with increased security to comply with the Police Secured By Design requirements.
